Product Features
Automatically operates the school/college bell or siren at your required period
Variable bell ringing durations (long bell and normal bell)
Separate timings can be set for Saturday
Bell will not ring on Sunday
Product comes with 20 (twenty) period settings
2 bells/sirens can be connected to single unit
Applications: school/college bells, factory sirens etc
Product Dimension: 120MMX130MMX60MM
Product Warranty : 1 Year from the date of purchase.
Operating Instructions
When the mains is ON, the display shows real time as shown below:
Press SET button. Display shows as shown below:
1 TIMER: MON-FRI
2 TIMER:SATURDAY
Use UP and DOWN buttons to select timings for Monday to Friday (week days) and press SET button.
Press SET button again to set timings for 1st bell.
Using SET, UP and DOWN buttons set timings for 1st bell
Set bell ringing duration from 1 second to 59 seconds
Press SET button again.
Press UP button to select bell 2
Follow same procedure as set for BELL 1
Same way set timings up to bell 20.
After 20th bell display shows as shown below:
Press SET button to exit to main menu
3 TIMER: MON-FRI
4 TIMER:SATURDAY
Using down button, select Saturday timings and set all 20 bell timings.
Note: If bell ringing is not required for any particular bell, set bell duration 00 for that bell.
