Product Dimension : 175MMX180MMX85MM
Product Warranty : 6 months from the date of purchase.
Download User Manual (PDF)
How Maya switch works?
SMS a unique code to Maya switch from your mobile to register your mobile number. You can register 3 mobile numbers. Maya switch works from the registered mobile numbers only.
You can operate the pump set in two modes .i.e., S.M.S mode and CALL mode.
In S.M.S mode you can operate your pump set by sending S.M.S and in CALL mode by voice call.
You have to call the SIM number you have inserted in Maya Switch unit. Your call will be received and you will hear a voice reply in your local language telling about the present status of pump set and status of power supply. You will be given voice instructions how to on/off the pump set or to set timer.
There will be three MODES of operation:
- Manual
- Auto
- Timer
You can select any one of above 3 modes by sending SMS to Maya switch number as MANUAL, or AUTO or TIME.
Manual mode: You can just ON/OFF by sending SMS or calling from your mobile. There will not be automatic start during power cuts.
Auto mode: Pump set automatically restarts during power cuts.
Timer mode: You can set running Time of motor through SMS (minimum 5 minutes to maximum 10 hours) You will receive all feed backs through SMS (provided the SIM card inside Maya switch has enough balance!!)
Operating Instructions
Operating by Voice Call:
1st call to Maya switch: Voice reply saying the status of pump set
2nd call to Maya switch (within 2 minutes after 1st call): Voice reply with action
Operating by SMS:
SL No. |
SEND MESSAGE |
ACTION |
RETURN MESSAGE |
1 |
MAYA1 |
To save 1st mobile number |
NUMBER SAVED |
2 |
MAYA2 |
To save 2nd mobile number |
NUMBER SAVED |
3 |
MAYA3 |
To save 3rd mobile number |
NUMBER SAVED |
4 |
ON |
To ON the pump set |
Status message |
5 |
OFF |
To OFF the pump set |
Status message |
6 |
STS |
To know the present status of pump set |
Status message |
7 |
MANU |
To set manual mode |
Status message |
8 |
AUTO |
To set auto mode |
Status message |
9 |
TIME HHMM |
To set time |
Status message |
Example: To set 2 hours 30 minutes: Send message as "TIME0230" Maximum settable time 9 hours 59 minutes. |
10 |
RST |
To reset timer |
TIMER RESET,PUMP ON |
11 |
|
When timer period is over |
TIMER OVER,PUMP OFF |
12 |
|
During starter over load trip |
NO LOAD, PUMP OFF |
13 |
|
During line fault |
LINE FAULT, PUMP OFF |
14 |
|
During power ON |
POWER ON,Status message |
PLEASE NOTE: All SMS should be in capital letters. POWER ON message comes to MAYA1 mobile only.
PLEASE WAIT UNTIL THE SIGNAL L.E.D LIGHTS UP AFTER MAINS ON
